Tool · Stud decoder

What does 600S162-54 mean?

Type any light-gauge steel member designation. The decoder reads the web depth, member type, flange width and minimum thickness in mils, and draws the section.

Try,,,,

  • SFIA designation system
  • Mils, gauge and color code

CSLB #951030 · first issued 2010 · verify on cslb.ca.gov (opens in a new tab)

  1. 600Web depth6.00 in
  2. SMemberStud or joist
  3. 162Flange1.62 in
  4. 54Thickness54 mils · ≈16 ga

600S162-54: a 6.00 in stud or joist, 1.62 in flange, 54 mils.

Web depth

6.00 in

Member

Stud or joist (C-section with lips)

Flange

1.62 in

Thickness

54 mils minimum base metal

≈16 ga · design 0.0566 in

End color

Green

Use

Structural range (ASTM C955): load-bearing walls, joists and framed openings when engineered.

6.00"1.62"
Cross-section drawn to scale from the designation. Lip length is illustrative.

Gauge numbers are approximate; specify members by mils. Color codes are common manufacturer conventions, not a code requirement. See the mils and gauges guide for sources, or look a word up in the glossary.
